Cisco Intercloud Services

Cisco Intercloud Services (CIS) is a Cisco owned and operated cloud platform that was first launched in partnership with Telstra in November 2014, delivered out of Telstra’s Clayton, Victoria, data centre, based on OpenStack orchestration and KVM as the underlying Hypervisor.

In a similar way to Telstra’s owned and operated cloud solutions, CIS is also able to connect Telstra customers back to their private Next IP network for a minimal fee.

Availability

Cisco Intercloud Services (CIS) are currently available in the following Telstra operated data centres:

  • Melbourne, Australia

More data centre locations are planned with some of the region’s already in-build. CIS will offer Telstra and Cisco customers a consistent architecture based on OpenStack with APIs globally.

Managing your Infrastructure

You can manage your infrastructure using two different methods. The first being Horizon, OpenStack’s web based management console.

The second option for management is not for the faint hearted – using the APIs. The OpenStack APIs provide a command line interface that allow you to automate the deployment and management of your environment.

Service and Contract Terms

Cisco Intercloud Services is available on a consumption based model whereby you pay for the resources that you consume, by the hour. There are no plans, monthly commitments or reserved instances at the time of writing.

Please have a look at the following page that provides more information about Cisco Intercloud Services.

Service Management

Service Management is provided to customers via their management console, MyCloud.telstra.com.

Read More

csx_dedicated

Telstra Virtual Server (dedicated)

Virtual Server (dedicated) aka CSX, DH on CSX

Virtual Server (Dedicated) is a Telstra owned and operated Infrastructure-as-a-Service platform, delivered out of Telstra’s data centres and virtualised with VMware vSphere 5.

It has been in market since the start of 2014 as a successor to Telstra’s Tailored Infrastructure solution and is available both domestically and globally. No matter where you activate your service, you are able to connect your virtual data centre’s to your private Next IP network for a $100 once fee per virtual data centre.

Availability

The Virtual Server (Dedicated) / DH on CSX environment is currently available in the following Telstra operated data centres:

  • Melbourne, Australia
  • Sydney, Australia
  • Perth, Australia
  • London, United Kingdom
  • Hong Kong
  • Singapore
  • United States (US East)

Telstra’s Virtual Server shared and dedicated solutions provide customers with a consistent architecture and connectivity in all data centres, globally.

Networking

The private network interconnect is a real differentiator when it comes to the market. You have your virtual infrastructure connected to the core of your network for virtually no cost. It makes even more of an impact when you gave two geographically separated instances and you want to replicate data between them. Bandwidth is provided by a bandwidth-in-abundance model, meaning that you get access to extreme speeds at no additional costs and Telstra manages the links.

To allow you to configure and manage your solution securely, you can also create up to 10 SSL VPN connections at no additional charge. The SSL VPN allows you to manage your virtual infrastructure, but it’s not designed to be a remote access solution.

Managing your Infrastructure

You get access to the vSphere client and vCenter. When your solution is first deployed you are given an SSL VPN connection and a “jump box”. The jump box is simply a Windows Server with the vSphere client installed.

Once connected, you can log in and begin create your templates, deploying and manage your virtual instances. If you have a large amount of data or virtual machines that you would like to import, please refer to the data import service that is currently available in Australian data centres.

You can go ahead and customise things. You can also install automation tools such as Power-CLI and backup and replication software such as VEEAM backup and recovery. We have published a whitepaper on using VEEAM in the DH on CSX environment.

Software and Licensing

The majority of customers elect to activate the Customer Managed service option. Under this option, Telstra manages the physical infrastructure, VMware and the VMware licensing.

Telstra does not provide software licensing on a monthly basis (SPLA) however, they are able to assist you with the purchase via their full catalogue of software applications. To get access to the software catalogue, you will need to get in touch with your aligned cloud specialist.

Service and Contract Terms

The Virtual Server (dedicated) platform is available with flexible terms, ranging from a simple monthly agreement to a full 36 month agreement with maximum discounting. Your discount value is based on the term of your commitment.

Please note: It is only the blade servers that are contracted. Storage, networking and the rest are all offered on a monthly term.

Please have a look at the following Cloud Infrastructure Pricing Guide.



Service Management

This shared and dedicated cloud infrastructure services above are managed using Telstra’s Cloud Services Management Console (CSMC). The CSMC includes a full library of documentation that will help you getting up and running.

Support and Assistance:

Telstra provides a 24/7/365 service operation. The service desk is your first point of call when you require assistance or would like to report an issue.

The service desk is available via telephone and email

You can reach the service desk with the details listed on the help and support page.

Read More

csx_shared

Telstra Virtual Server (shared)

Virtual Server (shared) aka CSX, Utility Hosting

Virtual Server (Shared) is a Telstra owned and operated Infrastructure as a Service platform, delivered out of Telstra’s data centres, running on shared infrastructure with each virtual data centre logically separated.

It has been in market since late 2011 and is available both domestically and globally. No matter where you activate your service, you are able to connect your virtual data centre’s to your private Next IP network for a $100 once fee per virtual data centre.

Availability

The DH on CSX environment is currently available in the following Telstra operated data centres:

  • Melbourne, Australia
  • London, United Kingdom
  • Hong Kong
  • Singapore
  • United States (US East)

Networking:

The private network interconnect is a real differentiator when it comes to the market. You have your virtual infrastructure connected to the core of your network for virtually no cost. It makes even more of an impact when you gave two geographically separated instances and you want to replicate data between them. Bandwidth is provided by a bandwidth-in-abundance model, meaning that you get access to extreme speeds at no additional costs and Telstra manages the links.

To allow you to configure and manage your solution securely, you can also create up to 10 SSL VPN connections at no additional charge. The SSL VPN allows you to manage your virtual infrastructure, but it’s not designed to be a remote access solution.

Building Virtual Servers:

The platform allows you to provision new virtual servers based on a defined set of operating system templates including Windows and Linux, using your web browser.

The currently available list of operating systems include:

  • CentOS® 5.x (32/64-bit)
  • CentOS 6.x (32/64-bit)
  • Red Hat Enterprise Linux 5.x (32/64-bit)
  • Red Hat Enterprise Linux 6.x (32/64-bit)
  • SUSE Enterprise Linux 10 (32/64-bit)
  • SUSE Enterprise Linux 11 (32/64-bit)
  • Microsoft Windows Server 2003 – Enterprise R2 (32*/64-bit)
  • Microsoft Windows Server 2008 – Enterprise SP2 (32*/64-bit)
  • Microsoft Windows Server 2008 – Enterprise R2 (64-bit)
  • Microsoft Windows Server 2008 – Web R2 (64-bit)
  • Microsoft Windows Server 2012 – Data Center (64-bit)
  • Microsoft Windows Server 2012 – Data Center R2 (64-bit)

Software Applications:

You can also pick from a range of add-on’s to complete your solution. This includes software and application licensing, network and security solutions, backup solutions and data import and export.

The currently available software applications include:

  • Microsoft Dynamics CRM Server 2013
  • Microsoft Exchange Server 2013
  • Microsoft Lync Server 2013
  • Microsoft SharePoint Server 2013
  • Microsoft SQL Server 2013
  • Microsoft Remote Desktop Services
  • Microsoft Office 2013 with Remote Desktop Services

Please also browse the following related links:



Please note:

Because the virtual machines run on shared physical infrastructure, certain software such as Microsoft Office is prohibited by its licensing terms from running on another vendors shared platform. To overcome this, Telstra provides the following operating systems and software licensing available for your consumption on a monthly basis.

Service and Contract Terms

The virtual server (shared) platform is available on a monthly agreement. There are also a number of plans that allow you to get additional pools of resources based on a minimum monthly commitment.

Please have a look at the following plans and pricing page.

Service Management

This shared and dedicated cloud infrastructure services above are managed using Telstra’s Cloud Services Management Console (CSMC). The CSMC includes a full library of documentation that will help you getting up and running.

Support and Assistance:

Telstra provides a 24/7/365 service operation. The service desk is your first point of call when you require assistance or would like to report an issue.

The service desk is available via telephone and email

You can reach the service desk with the details listed on the help and support page.

Read More

cloud_header

Telstra Cloud Services–What’s available today and what’s coming soon?

I’ve been meaning to write this post for some time to give you a clear understanding of what is available from Telstra today, and what’s coming up in the next six or so months.

As you have no doubt aware, Telstra has elected to partner with best of breed global cloud providers to build their cloud portfolio. This strategy will ultimately give our customers a greater breadth of available solutions, all connecting back to their existing Telstra Next IP private networks at close to $0.

Telstra’s current Infrastructure as a Service platforms include:

  • Virtual Server (shared): a virtual server compute platform virtualised with VMware on shared physical infrastructure
  • Virtual Server (dedicated): a virtual server compute platform virtualised with VMware on dedicated compute infrastructure. It also includes VMware access and options for incredibly fast hard disks
  • Cisco Intercloud Services (CIS): an OpenStack based public cloud offering virtualised on KVM providing a competitive public cloud offering
  • IBM Softlayer: a unique infrastructure as a service offering that has everything from bare metal servers to virtualisation and shared services
  • VMware vCloud Air: VMware’s owned and operated cloud platform including dedicated resources, virtual private cloud and a great DR as a Service offering

In the coming weeks, I’ll write up a post on each of the platforms above and update the links to the articles.

Telstra’s Cloud Direct Connect offerings include:

Telstra’s Cloud Direct Connect service offering allows our customers to connect their cloud services directly to their office via a layer 2 network solution, or as a direct connection into their private Next IP network via a layer 3 network solution.

Cloud Direct Connect services deliver high bandwidth private network connections between our customers and their cloud platform of choice.

Private Network connections do not travel over the public Internet. They offer more reliability connectivity with lower latency and are more secure than typical connections over the Internet. Unlike the internet, you are also able to get an end to end SLA with private connectivity.

In cases where terabytes of traffic are transferred on a monthly basis, financial benefits are realised quickly, in addition to the security benefits.

Our current Cloud Direct Connect offerings include:

  • Amazon Web Services (available now)
  • Microsoft Azure (available circa March 2015)

Telstra’s Recently announced Infrastructure as a Service platforms include:

  • CSX Cloud Infrastructure – US East: this is a newly announced Telstra Cloud point of presence in New York and will be based on the CSX cloud platform
  • Government Cloud – Australia: this is a newly announced Telstra Cloud point of presence in Canberra, Australia. The cloud is likely to be connected up to the Federal Government Managed Secure Network Gateway that Telstra operates to allow agencies to communicate securely.
  • Cisco Cloud Services – Hong Kong: as part of Cisco and Telstra’s go to market strategy and the intercloud magic, Hong Kong has been announced as an upcoming point of presence.
  • Cisco Cloud Service – Singapore: as part of Cisco and Telstra’s go to market strategy and the intercloud magic, Singapore has been announced as an upcoming point of presence.
  • VMware vCloud Air – Melbourne: Telstra and VMware have teamed up to launch the first vCloud Air cloud footprint in Australia from Telstra’s Clayton, Victoria, data centre.

The key benefits of buying cloud through Telstra are:

  • Single pane of glass: a high level overview of all cloud service in one location
  • Best of breed platforms: all the best cloud platforms becoming available to you as a Telstra customer
  • Next IP connectivity: first class private connectivity to your Telstra Next IP (private) network at almost no additional cost
  • Technology Funds: a great way to offset the costs of moving to the cloud
  • Reduced vendor management: All services billed through a single provider

Read More
